Getting species lineage — Krzysztof Kus

You have a list of species names and you need the full lineage for each one, so you can group, filter or colour by clade. It sounds like a solved problem. In practice every tool I tried wanted either a web service I would be hammering a few thousand times, or a database I did not want to stand up for a one-off annotation.

This script reads the NCBI Taxonomy dump files directly and walks the tree itself. It runs offline, needs nothing beyond the standard library, and finishes in seconds.

Getting the data

Download taxdmp.zip from the NCBI Taxonomy FTP and unzip it. You want nodes.dmp, which holds the parent–child relationships, and names.dmp, which maps taxonomy IDs to names. Put a copy of the script below in the same directory.

Running it

Prepare a plain text file with one species per line, then:

python3 species_lineage.py species_example.txt

The script writes species_lineage.txt, with each lineage on its own line and the ranks separated by a pipe. Two things get flagged rather than silently dropped: names that are not two words, which is usually a formatting problem with viruses excepted, and names absent from the taxonomy, which in my experience is nearly always a typo.

How it works

read_dump loads a dump file into a dictionary, keyed on taxonomy ID. walk_to_root climbs from a species node to the root by repeatedly looking up its parent, stopping at taxonomy ID 1, at a node that is its own parent, or at any ID it has already visited — that last guard means a malformed dump gives you a short lineage rather than an infinite loop. lineage_string converts the resulting chain of IDs back into names, reversed so the lineage reads from the root down to the species, which is the order you expect on the page.

#!/usr/bin/env python3
"""Annotate a list of species with its full NCBI Taxonomy lineage.

    python3 species_lineage.py species.txt

Writes species_lineage.txt beside the input. Reads the NCBI Taxonomy dump
files directly and walks the tree itself, so it runs offline and needs
nothing beyond the standard library.

Get the dumps with:

    wget https://ftp.ncbi.nlm.nih.gov/pub/taxonomy/taxdump.tar.gz
    tar -xzf taxdump.tar.gz nodes.dmp names.dmp

The sample nodes.dmp and names.dmp shipped alongside this script are a tiny
excerpt in the same format, enough to run the example without the 400 MB
download.
"""

import argparse
import os
import sys

FIELD_SEP = "\t|\t"
ROOT_TAXID = "1"


def read_dump(path, key_col, value_cols, keep_only=None):
    """Map one column of an NCBI .dmp file to one or more of the others.

    NCBI separates fields with "\t|\t" and ends each line with "\t|", so the
    final column carries a trailing separator that has to come off.
    """
    table = {}
    with open(path, encoding="utf-8") as handle:
        for line in handle:
            if keep_only is not None and keep_only not in line:
                continue
            fields = line.rstrip("\n").rstrip("\t|").split(FIELD_SEP)
            try:
                if len(value_cols) == 1:
                    table[fields[key_col]] = fields[value_cols[0]].upper()
                else:
                    table[fields[key_col]] = [fields[c].upper() for c in value_cols]
            except IndexError:
                # a short or malformed line is skipped rather than fatal
                continue
    return table


def invert(table):
    """Name -> taxid, from the taxid -> name mapping."""
    return {value: key for key, value in table.items()}


def walk_to_root(nodes, taxid):
    """Every taxid from this node up to the root, child first.

    Guards against a node that is its own parent and against a cycle in a
    hand-edited dump, either of which would otherwise loop forever.
    """
    lineage = [taxid]
    seen = {taxid}
    while True:
        entry = nodes.get(taxid)
        if not entry:
            break
        parent = entry[0]
        if parent == taxid or parent == ROOT_TAXID or parent in seen:
            break
        lineage.append(parent)
        seen.add(parent)
        taxid = parent
    return lineage


def lineage_string(taxids, names):
    """Root first, which is the order people expect to read a lineage in."""
    return "|".join(names.get(t, "?") for t in reversed(taxids))


def annotate(species_file, nodes, names, names_reversed, out_handle):
    written = 0
    for line in species_file:
        words = line.strip().split()
        if not words:
            continue
        species = " ".join(words).upper()

        if len(words) != 2 and "VIRUS" not in species:
            out_handle.write(
                species + "|Species name should consist of two words "
                "if it is not a virus\n")
            continue

        taxid = names_reversed.get(species)
        if taxid is None:
            out_handle.write(species + "|Not found — most likely a typo\n")
            continue

        out_handle.write(lineage_string(walk_to_root(nodes, taxid), names) + "\n")
        written += 1
    return written


def main(argv=None):
    parser = argparse.ArgumentParser(description=__doc__.splitlines()[0])
    parser.add_argument("species", help="text file, one species per line")
    parser.add_argument("--nodes", default="nodes.dmp")
    parser.add_argument("--names", default="names.dmp")
    parser.add_argument("-o", "--out", help="defaults to <input>_lineage.txt")
    args = parser.parse_args(argv)

    for path in (args.nodes, args.names, args.species):
        if not os.path.exists(path):
            parser.error(f"no such file: {path}")

    nodes = read_dump(args.nodes, 0, [1, 2])
    names = read_dump(args.names, 0, [1], keep_only="scientific name")
    names_reversed = invert(names)

    out_path = args.out or os.path.splitext(args.species)[0] + "_lineage.txt"
    with open(args.species, encoding="utf-8") as species_file, \
            open(out_path, "w", encoding="utf-8") as out_handle:
        written = annotate(species_file, nodes, names, names_reversed, out_handle)

    print(f"wrote {out_path} ({written} lineages resolved)", file=sys.stderr)
    return 0


if __name__ == "__main__":
    raise SystemExit(main())

The script is Python 3 and uses only the standard library. It is available below, along with a small excerpt of the taxonomy — enough to run the example without the 400 MB download — and a species list that deliberately includes a typo and a one-word name so you can see both error paths.

Download

python3 species_lineage.py species_example.txt
